Catalogue Nessie

Aperçu​

Project Nessie is an open-source transactional data catalog that brings Git-like version control to data lakes. It enables you to manage multiple versions of your data using branches, tags, and commits, similar to how Git manages source code.

With Ilum’s integration, you can leverage Nessie’s version control features directly in your Spark environment. This allows you to branch, tag, and merge data changes safely and efficiently.

Unlike traditional Hive or Glue catalogs, which only track the latest state of each table, Nessie records all changes as commits in a timeline. Each commit represents a consistent snapshot of your data lake. Changes are isolated until committed, ensuring incomplete or in-progress updates are never visible to other users or jobs. Once finalized, changes become atomically visible, guaranteeing consistency.

Key Features: Nessie vs. Traditional Catalogs​

CaractéristiqueTraditional CatalogsCatalogue Nessie
BranchingNoYes (Git-like)
Isolated EnvironmentsManual/ComplexSimple, via branches
Commit History & Time TravelLimited/Per-tableFull catalog history
Multi-table TransactionsNoYes (atomic commits)
Collaboration & GovernanceMinimalBuilt-in, audit log

Highlights​

  • Branching: Create multiple isolated branches (e.g., principal, Dev, staging) without duplicating data. Branches are lightweight pointers to metadata snapshots.
  • Isolated Environments: Use the same data lake for dev, staging, and prod by isolating changes in branches. No need for separate catalogs or data copies.
  • Commit History & Time Travel: Nessie maintains a unified commit log. Inspect, audit, or time-travel to any previous state by commit hash or timestamp.
  • Atomic Multi-table Transactions: Commit changes across multiple tables as a single atomic operation. All succeed or none do.
  • Collaboration & Governance: Work on separate branches, merge changes, and track who changed what and when. Enables safe experimentation and robust auditability.

Core Concepts​

Branches​

Un branch is an independent line of development for your data catalog. Branches start as copies of existing branches and track changes separately. They are lightweight, referencing the same data files but different metadata. The default branch is usually principal.

Tags​

Un tag is a read-only label pointing to a specific commit. Use tags to mark stable versions or important milestones (e.g., v1.0, 2025-06-release). Tags are immutable bookmarks.

Commits​

Un commettre is a set of changes recorded as a single atomic unit. Each commit has a unique ID, timestamp, author, and optional message. The commit log provides full catalog versioning.

Using Nessie in Ilum​

avertissement

Nessie is not enabled by default in Ilum. To enable it, see the production page.

Ilum supports Project Nessie as a catalog for version-controlled data management. When using Ilum notebooks or Spark jobs with Apache Iceberg, Git-like operations (branching, merging, tagging) can be performed directly via SQL.

There are two ways to wire Nessie into a cluster: the chart-managed flow, recommended for Helm deployments, and the manual flow, for self-managed Spark images or clusters configured outside the chart.

note

Nessie SQL operations (USE BRANCH, CREATE BRANCH, MERGE BRANCH, and the rest of the walkthrough below) are supported on both the Spark 3.5 and Spark 4.x image lines. Use the matching ilum/spark:-nessie image, for example ilum/spark:3.5.8-nessie ou ilum/spark:4.1.2-nessie. The Spark 4.x image ships nessie-spark-extensions-4.0_2.13, which is ABI-compatible with the Spark 4.1 line (no native 4.1 build is published yet), mirroring the iceberg-spark-runtime-4.0_2.13 it pairs with.

When Ilum is deployed with the Helm chart, the Nessie catalog is configured declaratively. Enable the metastore and set its type to nessie dans le ilum-core values (the example uses the umbrella-chart key; in the standalone helm_core chart the same keys live at the top level):

ilum-core:
  metastore:
    Activé: vrai
    type: nessie
    nessie:
      address: http://ilum-nessie:19120
      warehouseDir: s3a://ilum-data/nessie_catalog/
      s3Endpoint: http://ilum-objectstorage:9000/
      s3PathStyleAccess: vrai
      ref: principal
      catalogName: nessie_catalog
nessie:
  Activé: vrai

The Iceberg + Nessie catalog wiring — spark.sql.extensionsle SparkCatalog provider, catalog-impl (NessieCatalog), and io-impl (S3FileIO) — is generated by ilum-core under the configured catalogName; it does not need to be set in values. Ilum injects it, together with the connection settings above (URI, ref, warehouse, S3 endpoint, path-style, and region) and the catalog's S3 credentials (taken from the cluster's object-storage credentials, never persisted on the metastore), into every Spark submission on a cluster that has the metastore attached. No catalog wiring, extraJavaOptions, or credentials need to be set on the cluster or in the notebook session — a chart-managed Nessie catalog works out of the box.

Avec metastore.enabled: true, the bundled faire défaut cluster is attached to this metastore automatically, so jobs on it resolve the catalog out of the box. The catalog is addressed by metastore.nessie.catalogName (default nessie_catalog); tables are referenced as nessie_catalog..

throughout the SQL examples below.

To attach the metastore to another cluster, open its Edit Cluster tab and select Nessie in the General metastore dropdown:

Catalog Selection

Manual configuration​

For a cluster running a self-managed Spark image, or when Nessie is configured outside the chart, the nessie_catalog must be pre-configured in the Spark session.

Make sure the Spark image used in the cluster has the Nessie client installed. In particular, the following are required:

  • Iceberg Spark Runtime (org.apache.iceberg:iceberg-spark-runtime-_) - Required for Nessie support.
  • Iceberg AWS Bundle (org.apache.iceberg:iceberg-aws-bundle) - Required for S3 support.
  • Nessie SQL Extensions (org.projectnessie.nessie-integrations:nessie-spark-extensions-_) - Required for Nessie-specific SQL operations.

Ilum custom Spark image for Nessie: ilum/spark:-nessie includes all the required dependencies.

note

When the catalog URI targets the Nessie server's /api/v2 endpoint, also set spark.sql.catalog..client-api-version=2. The Iceberg-bundled Nessie client otherwise defaults to API v1 and the first catalog call fails with NessieApiCompatibilityException: API version mismatch.

avertissement

Ilum’s spark-nessie image does not include any Delta table dependencies, so the default cluster configuration for Delta tables must be removed when using this image (on a chart deployment, override these via kubernetes.defaultCluster.config). In particular:

NomValeur
spark.sql.catalog.spark_catalogorg.apache.spark.sql.delta.catalog.DeltaCatalog
spark.sql.extensionsio.delta.sql.DeltaSparkSessionExtension

Nessie Walkthrough​

In the beginning, it is recommended to create anything inside the main branch so that you avoid problems with merging into an empty branch:

CRÉER TABLE nessie_catalog.Utilisateurs(
    user_id INT,
    user_name VARCHAR(20)
);

Create a Branch​

CRÉER BRANCH dev IN nessie_catalog DE principal;

And to verify everything, list all branches and tags:

LIST REFERENCES IN nessie_catalog;

Work on a Branch​

Create a table and insert data in the Dev branch with the fully qualified name (@ ou @):

CRÉER TABLE nessie_catalog.`sales@dev`(
    sale_timestamp CHAR(10),
    sale_amount INT,
    payment_method VARCHAR(20)
);

INSÉRER DANS nessie_catalog.`sales@dev` VALEURS
    ('2025-06-01', 1000, 'Online'),
    ('2025-06-02', 1500, 'InStore'),
    ('2025-06-03', 800, 'Online'),
    ('2025-06-04', 1200, 'Mobile'),
    ('2025-06-05', 950, 'InStore');
CHOISIR COMPTER(*) DE nessie_catalog.`sales@dev`;

Or use the USE statement to switch a context to a specific branch:

USE BRANCH dev IN nessie_catalog;
CHOISIR COMPTER(*) DE nessie_catalog.ventes;
note

Because Ilum’s SQL executor treats each query as a stateless entity, using the USE statement requires executing all related statements together.
To do this, select the entire query block in the editor and then press exécuter.

And show the log of all commits done:

MONTRER LOG SUR Dev IN nessie_catalog;

Merge Branches​

MERGE BRANCH dev DANS principal IN nessie_catalog;
MONTRER TABLES IN nessie_catalog;
note

If you see an error of No common ancestor in parents of and , this can mean that the branch you are trying to merge into is empty. This will cause the merge to fail, even if the branch you are trying to merge was correctly created from the parent branch.

Cataloging Nessie Tables in OpenMetadata​

Iceberg tables managed in Nessie can be surfaced in OpenMetadata — Ilum's metadata catalog and governance layer — so that branched, committed, version-controlled tables become discoverable, classifiable, and lineage-connected assets alongside the rest of the data platform.

OpenMetadata reads Nessie through its Iceberg-REST endpoint (base URI http://ilum-nessie:19120/iceberg), cataloging the tables visible on a single reference. The reference is selected by the warehouse (default nessie_catalog → ref principal), not by the URI path. Nessie's branch/tag/commit history is flattened — OpenMetadata sees only the current state of that one reference, not the version timeline. The integration is opt-in and enabled with two values:

nessie:
  Activé: vrai
openmetadataBootstrap:
  services:
    iceberg:
      Activé: vrai

For the connector details, branch-semantics caveats, object-storage credential note, and full enabling reference, see Iceberg tables via Project Nessie on the OpenMetadata page.

note

This integration is newly added and opt-in. Its configuration is validated against the chart; the end-to-end result (a Nessie-committed Iceberg table appearing in the OpenMetadata catalog) is pending live verification. Treat it as a preview until confirmed.

Bonnes pratiques​

  • Develop in Isolation: Use branches for development or experiments. Promote changes through a hierarchy (e.g., dev → staging → main).
  • Merge Frequently: Merge changes regularly to minimize conflicts.
  • Keep Branches Short-Lived: Remove feature branches after merging.
  • Avoid Conflicts: Sync your branch with the latest target branch before merging.
  • Tag Milestones: Use tags for stable releases or important checkpoints.
  • Document Changes: Add commit messages for traceability.

Pour en savoir plus​

For advanced SQL operations and the full Nessie Spark SQL reference, see:
👉 Nessie Spark SQL Reference

Nessie with Ilum combines Spark’s power with Git-like data management, enabling robust “data as code” workflows for your lakehouse.
